BIRDY Rohloff

The "King" of Birdy bikes, the Birdy Rohloff is unflinchingly reliable and robust, a perfect companion for the longest journeys. Its 14-speed internal Rohloff gear hub has a massive 526% gear range and requires practically no maintenance. The grip twist gear shifting system is both ergonomic and comfortable, allowing you to shift up to 8 gears even while stationary.  To top off its impressive reputation, the Rohloff boasts puncture-resistant Schwalbe Marathon tyres and powerful TRP Spyre dual piston actuated brakes.

Full Rear and Front Suspension

The birdy Rohloff foldable bike had full front and rear suspension

Smoother ride, reducing fatigue

18” Schwalbe Marathon Racer Tyres

The birdy Rohloff foldable bicycle Schwalbe Marathon Tyre

Puncture-resistant performance tyres

4 simple steps to fold / unfold

The birdy Rohloff folding bicycle folds and unfolds

A compact performance folding bike

Legendary Rohloff Hub

The birdy Rohloff folding bike uses the Rohloff Hub

Massive 526% gear range with 14 evenly spaced gear ratios

TRP Spyre Brakes

The birdy Rohloff folding bike has TRP Spyre Disc brake

High performance mechanical dual pistons

Rohloff Twist Shifter

The birdy Rohloff foldable bike uses the Rohloff Twist shifter

Ergonomic & comfortable gear shifts

Gen 3 Monocoque Frame

The birdy Rohloff folding bike uses the Gen 3 Monocoque frame

No hinges in the frame, no compromises in ride quality

Full Front & Rear Suspension

Smoother ride,reducing fatigue

The birdy Rohloff foldable bike had full front and rear suspension

18” Schwalbe Marathon Racer Tyres

Puncture-resistant performance tyres

The birdy Rohloff foldable bicycle Schwalbe Marathon Tyre

4 Simple Steps to Fold / Unfold

A compact performance folding bike

The birdy Rohloff folding bicycle folds and unfolds

Legendary Rohloff Hub

Massive 526% gear range with 14 evenly spaced gear ratios

The birdy Rohloff folding bike uses the Rohloff Hub

TRP Spyre Brakes

High performance mechanical dual pistons

The birdy Rohloff folding bike has TRP Spyre Disc brake

Rohloff Twist Shifter

Ergonomic & comfortable gear shifts

The birdy Rohloff foldable bike uses the Rohloff Twist shifter

Gen 3 Monocoque Frame

No hinges in the frame, no compromises in ride quality

The birdy Rohloff folding bike uses the Gen 3 Monocoque frame

Fold And Unfold

GETTING TO KNOW the Birdy Rohloff

Next button
Next button

SPECIFICATIONS

Frame

Frame

Birdy G3 Monocoque 7005-T6 Aluminium

Fork

Hydroformed Front Suspension Fork w/ Disc Brake Mount

Rear suspension

90D PU Elastomer

Drive Train

Bottom Bracket

Driveline Hollowtech II compatible threaded 68mm

Chainwheel

Birdy Hollowtech II compatible 52T 170mm BCD:130mm w/double chainguard

Chain

Shimano HG-53

Cassette

Rohloff 13T Cog
*Rohloff SPEEDHUB 500/14 Disc
*Internal 14 Gear Anodized Black
**IGR 0.279-0.316-0.360-0.409-0.464-0.528-0.600-0.682-0.774-0.881-1.000-1.135-1.292-1.467
**IGR = Inner Gear Ratios (Hub Rotation per Sprocket Rotation)*

Chain Tensioner

Rohloff #8250 Chain Tensioner

Shifter

Rohloff Twist Shifter

Brakes

Brakes

TRP Spyre Disc Brake

Disc Rotor

Front: 6-Bolt Disc Brake Rotor 160mm
Rear: Rohloff 4 Bolt Disc Rotor 160mm

Brake Lever

TEKTRO FL-740 QR Type 3-Finger

Wheels

Tyre

Schwalbe Marathon Racer 18×1.5″ (40-355)

Rim

Alex DA16 Black Anodized
or
Alex DM18 Black Anodized

Hub

F: Birdy 32H / R: Rohloff 14-Speed 32H Black

Spoke

Stainless Steel 2.0mm (14G)

Cockpit

Head Sets

Semi Integrated 1-1/8″

Handlebar

Horizon AL6061T6 Butted, 31.8x540mm 10D

Stem

New Birdy Double Lock Adjustable Stem 10 Degree
(21 Degree Stem is sold separately at $425)

Seat

Seat Post

Birdy SP61R.1 34.9mm AL7075 Hard-Anodized w/ Laser Scale

Saddle

Selle SanMarco Model X

Accessories

Pedals

VP-197 Black Cage w/ BS Reflectors

Chain Tensioner

PCI Chain Tensioner

Bell

Bell (Black)

Optional Accessories

Kickstand, Rear Rack, Front Rack, Mudguards, etc. are Sold Separately

Dimensions

Estimated Dimensions

Folded: 60cm(H) x 39cm(W) x 72cm(L)

Rider Height

145 – 185cm

Weight

Weight

12kg (incl. Saddle & Pedals)

Max Load

110kg (incl. Rider & Luggage)

Add important notes:
1. Specifications are subject to change without notice.
2. Images are for illustration purposes only. Please refer to the specifications.
